LED Strip T-Shape 3-Way Splitter Connector
The T-shape 3-way splitter connector enables branching LED strip installations without soldering, allowing one main strip run to split into two separate branches at a 90-degree angle. This connector is compatible with 10mm wide LED strips including single-color, RGB, and RGBW variants, making it a versatile component for complex lighting layouts. The 3-way design supports 2-pin, 4-pin, and 5-pin configurations with the appropriate model selection.
Internally, each branch features independent spring-loaded copper contacts that maintain consistent pressure on the strip PCB pads regardless of temperature fluctuations. The self-locking hinge mechanism provides audible click feedback when properly engaged, helping installers verify correct connection at a glance. All contacts are nickel-plated for enhanced corrosion resistance in humid environments.
The compact T-junction body measures 25mm x 25mm x 10mm, allowing installation in standard aluminum profile channels without obstruction. Rated for 5A total current across all three branches, with each branch individually capable of handling 3A.
Specifications
| Parameter | Specification |
|---|---|
| Connector Type | T-Shape 3-Way Splitter |
| Compatible Strip Width | 10mm |
| Pin Configurations | 2-Pin / 4-Pin / 5-Pin |
| Contact Material | Copper, Nickel-Plated |
| Housing Material | Flame-Retardant PC |
| Total Max Current | 5A |
| Branch Max Current | 3A per Branch |
| Dimensions | 25mm x 25mm x 10mm |
The T-shape splitter connector is widely used in cabinet under-lighting systems, retail shelf illumination, exhibition booth lighting, and architectural cove lighting where branching LED strip runs are required. Available for single-color (2-pin), RGB (4-pin), and RGBW (5-pin) LED strip types.
