LED Strip End Cap Connector Set – Waterproof
Our waterproof LED strip end cap connector set provides professional-grade termination for LED strip installations, protecting exposed strip ends from moisture, dust, and physical damage. Each set includes both the connector cap and a silicone sealing gasket, achieving IP65-rated protection when properly installed. These end caps are essential for outdoor and bathroom LED strip applications where environmental protection is critical.
The end cap housing is manufactured from UV-stabilized polycarbonate, ensuring long-term durability under direct sunlight exposure without yellowing or becoming brittle. The internal contact assembly features tin-plated copper terminals that accept strip ends up to 12mm wide, accommodating both single-color and multi-channel LED strips. The integrated strain relief prevents wire fatigue at the connection point.
Installation involves inserting the prepared strip end, filling the cap cavity with the included silicone sealant, and allowing to cure for 30 minutes. Once sealed, the assembly withstands temperatures from -20°C to +85°C and maintains watertight integrity at depths up to 1 meter.
Specifications
| Parameter | Specification |
|---|---|
| Protection Rating | IP65 Waterproof |
| Compatible Strip Width | 8-12mm |
| Housing Material | UV-Stabilized Polycarbonate |
| Contact Material | Tin-Plated Copper |
| Temperature Range | -20°C to +85°C |
| Sealant Included | Yes (Silicone) |
| Cure Time | 30 Minutes |
| Quantity per Pack | 10 Pairs (20 Pieces) |
Recommended for outdoor landscape lighting, pool area accent illumination, marine LED installations, and any application where LED strip ends require environmental sealing. Bulk OEM packaging with custom branding available for qualified distributors.
