LED Strip Jumper Connector – 4-Pin RGB
The 4-pin RGB LED strip jumper connector provides a convenient solution for bridging gaps and making right-angle connections in RGB LED strip installations. Designed specifically for 10mm wide 4-pin RGB strips (common anode plus R/G/B channels), this jumper ensures consistent color output across joined sections with minimal voltage drop.
Each jumper connector utilizes high-grade phosphor bronze contacts with gold-plated terminals, offering superior corrosion resistance and reliable electrical performance over extended use. The flexible wire section measures 15cm in length, allowing for easy routing around corners, across cabinet gaps, and through partition walls. The wire is 22AWG stranded copper for excellent flexibility and current capacity.
The snap-fit connector housings lock securely onto the strip ends, preventing accidental disconnection from vibration or movement. LED indicators on the connector body provide visual confirmation of proper polarity alignment during installation, reducing troubleshooting time on large projects.
Specifications
| Parameter | Specification |
|---|---|
| Connector Type | 4-Pin Jumper with Wire |
| Compatible Strip | 10mm 4-Pin RGB |
| Wire Length | 15cm |
| Wire Gauge | 22AWG Stranded Copper |
| Contact Material | Phosphor Bronze, Gold-Plated |
| Max Current | 4A per Channel |
| Max Voltage | 24V DC |
| Housing Material | PVC + Polycarbonate |
These 4-pin jumper connectors are essential for professional RGB LED installations in architectural lighting, hotel lobby illumination, and commercial display applications where continuous strip runs are interrupted by structural elements. Suitable for 12V and 24V RGB LED strip systems.
