320W 24V IP67 LED Driver — Mean Well HLG-320H Compatible
The highest-capacity 24V driver in the HLG-compatible family, delivering 320W through a fully potted IP67 aluminum enclosure. Engineered for street lighting, area illumination, and large-scale outdoor LED installations where a single high-power driver reduces installation complexity and maintenance points. The 96% peak efficiency minimizes energy waste and thermal load, extending both driver and LED module lifespan in enclosed luminaire housings.
Key Features
- 320W / 13.3A output — Single-driver solution for large LED arrays, reducing component count and failure points in critical outdoor installations
- 96% peak efficiency — Among the highest in class, reducing annual energy costs by 15-20% compared to 90% efficiency alternatives over the driver’s lifetime
- IP67 hermetic seal — Fully potted with thermally conductive compound ensures heat transfer to the aluminum case while preventing moisture ingress
- 3-in-1 dimming — 1-10V, PWM, and resistance control for integration with photocells, timers, and smart city lighting management systems
- 6kV surge immunity — Withstands severe lightning transients without external SPD, critical for overhead street and pole-mounted installations
- -40°C to +90°C case temp — Qualified for Arctic winter startup through Middle Eastern summer rooftop operation
Technical Specifications
| Parameter | Value |
|---|---|
| Output Power | 320W (24V / 13.3A) |
| Input Voltage | 90-305VAC / 127-431VDC |
| Efficiency | 96% typical |
| Power Factor | >0.99 |
| Dimming | 3-in-1: 1-10V / PWM / Resistance |
| IP Rating | IP67 |
| Surge Protection | 6kV common mode / 4kV differential |
| Protection | OCP, OVP, OTP, short-circuit |
| Operating Temp | -40°C to +90°C (case) |
| Dimensions | 252 × 78 × 50 mm |
| Weight | 1350g |
| Certifications | CE, CB, EAC, UL8750, FCC Class B |
| Warranty | 5 years |
| Mean Well Equivalent | HLG-320H-24A |
Applications
- Municipal LED street lighting and roadway illumination
- Parking lot and area flood lighting retrofits
- Sports field perimeter and accent lighting
- Large LED billboard and signage installations
- Industrial facility exterior security lighting
Installation Notes
Mount to a flat surface using M4 stainless steel bolts through the integrated mounting tabs. For street light pole installations, position the driver at the base of the luminaire where ambient temperature is lowest. Connect the 1-10V dimming wires to the matching terminals — polarity matters for 1-10V but not for PWM or resistance dimming. Use MC4-compatible cable glands for outdoor cable entries.
Why Choose BrightLink
Our HLG-320H-compatible driver delivers the same 96% efficiency and 6kV surge protection as Mean Well at 35% lower cost. Each unit ships with full test report documenting output voltage accuracy, efficiency curve, and Hi-Pot results. Municipal and distributor value for 10+ units.
