LED Power Supply – 12V 30W Mini Driver

LED Power Supply 12V 30W Miniature Compact LED Driver

The 12V 30W mini LED power supply is the smallest constant-voltage driver in our range, purpose-designed for compact LED lighting applications where space is at a premium and power requirements are modest. Measuring just 98 x 43 x 23mm, this miniature driver fits inside small luminaire housings, tight junction boxes, and compact furniture cavities without compromising on electrical safety or output stability. Despite its pocket-sized footprint, it delivers a regulated 12VDC at up to 2.5A with full protection circuitry and global AC input compatibility.

This mini driver uses high-efficiency synchronous rectification topology to achieve up to 86% efficiency in a sealed, potting-filled enclosure that provides passive cooling and mechanical protection. The fanless design ensures zero acoustic noise, making it suitable for bedroom, hospitality, and healthcare lighting environments where audible electronics are unacceptable. With a no-load consumption below 0.3W, it meets the most stringent standby power regulations across Australia, Europe, and North America.

BluxLED supplies this 12V 30W mini LED driver to lighting manufacturers, shopfitters, and electrical wholesalers who need a reliable compact driver for small-scale LED installations. We offer aggressive volume options, OEM branding, and custom packaging for private-label distribution programs. All units are CE and RoHS certified and undergo 100% production testing. Contact our export team for quotation and sample requests.

Key Features

• Ultra-compact dimensions: 98 x 43 x 23mm for the tightest installation spaces
• 12VDC constant voltage output at 30W (2.5A)
• High-efficiency synchronous rectification topology (up to 86%)
• Fully potted sealed enclosure for mechanical and moisture protection
• Fanless passive cooling with zero acoustic noise output
• Universal AC input: 100-265VAC for worldwide mains compatibility
• Ultra-low no-load consumption below 0.3W
• Integrated protections: short-circuit, over-current, over-voltage
• CE and RoHS certified with EN61347 compliance

Technical Specifications

Parameter	Specification
Output Voltage	12VDC
Output Power	30W
Output Current	0-2.5A
Voltage Tolerance	+/-5%
Input Voltage Range	100-265VAC
Input Frequency	47-63Hz
Power Factor	> 0.7 (at full load, 230VAC)
Efficiency	Up to 86%
Ingress Protection	IP20 (sealed enclosure)
Operating Temperature	-20°C to +50°C
Storage Temperature	-40°C to +85°C
Protection	Short-circuit / Over-current / Over-voltage
Cooling	Passive (potted enclosure)
Enclosure Material	PC plastic, fully potted
Dimensions (L x W x H)	98 x 43 x 23 mm
Weight	Approx. 95g
Certifications	CE, RoHS, EN61347
MTBF	> 35,000 hours
Warranty	2 years

Applications

• Under-cabinet LED strip lighting in kitchens and laundries
• Small showcase and display case LED illumination
• Bathroom mirror LED backlighting in residential and hospitality settings
• Furniture-integrated LED lighting in desks, shelves, and bed frames
• Stair tread and handrail LED strip lighting
• Small signage and wayfinding LED illumination
• Bedroom and nursery low-power ambient LED lighting

Frequently Asked Questions

What is the smallest LED strip length this 12V 30W mini driver can power?

This driver can power LED strip runs from as little as 0.5 metres up to approximately 2 metres of standard 14.4W/m strip (at 80% load). It is suitable for both small accent installations and moderate-length runs where a compact driver is needed.

Can this mini driver be hidden inside a wall cavity?

Yes. The compact size and sealed potted construction make this driver suitable for concealment inside wall cavities, ceiling recesses, and behind plasterboard access panels. Ensure the driver is accessible for maintenance or replacement, and maintain clearance around the unit for heat dissipation.

Is this driver suitable for powering individual LED downlights?

This driver can power 12V LED downlights as long as the total wattage does not exceed 30W (recommend 24W at 80% load). For example, it can drive up to 4-6 x 5W 12V LED downlights. Ensure the downlights are 12VDC constant-voltage type, not constant-current.

Does this mini driver get hot during operation?

The driver operates with passive cooling through its potted enclosure. Under full load, the case temperature may reach 45-55°C, which is warm but within safe touch limits. The sealed design limits heat dissipation, so ensure the installation location has some air movement and is not insulated directly against the driver.

What is the MOQ for ordering this mini LED driver?

Standard MOQ is 500 units due to the high-volume nature of this compact product. Tiered value applies at 1000, 3000, and 5000-unit levels. OEM branding orders start at 1000 units. Sample packs of 5-10 units are available for evaluation.

Can I order this driver with pre-fitted output cables?

Yes. While the standard model uses screw terminal connections, we can supply units with pre-fitted output cable pigtails (typically 150mm or 300mm lengths) for faster installation in production environments. Custom cable lengths and connector types are available for OEM orders.

What is the difference between this mini driver and the 12V 60W slim driver?

The 30W mini driver is significantly smaller (98 x 43 x 23mm vs 160 x 50 x 19mm) and offers half the power output. Choose the 30W mini when space is the primary constraint and power requirements are low. Choose the 60W slim when you need more power but still require a low-profile form factor.
