150W 24V IP67 LED Driver — Mean Well HLG-150H Compatible
Direct replacement for the Mean Well HLG-150H-24, delivering 156W of continuous output in a fully potted IP67 aluminum housing. Engineered for outdoor LED signage, facade lighting, and landscape installations where reliability under extreme weather is non-negotiable. The 3-in-1 dimming interface supports 1-10V, PWM, and resistance-based control, making it compatible with virtually every commercial dimming system on the market.
Key Features
- 156W continuous output at 24V — 6.5A max current, driving up to 40 meters of standard-density 24V LED strip or 200+ LED modules
- IP67 + IP65 dual rating — Fully potted internals survive submersion (IP67) while the housing provides IP65 protection for exposed mounting
- 3-in-1 dimming — 1-10V analog, PWM signal, and resistance adjustment — no external dimmer module required
- 90-305VAC universal input — Handles voltage fluctuations common in outdoor installations, including 277V commercial mains
- 95% typ. efficiency — Minimal heat generation enables natural convection cooling from -40°C to +80°C ambient without derating until 70°C
- Built-in active PFC — Power factor >0.99 reduces utility penalties and meets IEC 61000-3-2 harmonic requirements
Technical Specifications
| Parameter | Value |
|---|---|
| Output Power | 156W (24V / 6.5A) |
| Input Voltage | 90-305VAC / 127-431VDC |
| Efficiency | 95% typical |
| Power Factor | >0.99 (active PFC) |
| Dimming | 3-in-1: 1-10V / PWM / Resistance |
| IP Rating | IP67 (internals) / IP65 (housing) |
| Protection | OCP, OVP, OTP, short-circuit |
| Operating Temp | -40°C to +80°C |
| Dimensions | 200 × 68 × 40 mm |
| Weight | 780g |
| Certifications | CE, CB, EAC, UL8750, FCC Class B |
| Warranty | 5 years |
| Mean Well Equivalent | HLG-150H-24 |
Applications
- Outdoor LED facade and architectural lighting
- LED signage and billboard illumination
- Landscape and pathway lighting systems
- Commercial awning and canopy lighting
- Marine and waterfront LED installations
Installation Notes
Mount using the integrated mounting tabs or stainless steel cable ties. For 1-10V dimming, connect the dimmer wires to the dedicated Dim+/Dim- terminals. Ensure the cable entry glands are tightly sealed to maintain IP67 rating. Always de-energize before wiring.
Why Choose BrightLink
direct-from-manufacturer value at 30-40% below Mean Well retail cost with equivalent performance and full certification documentation. 5-year warranty, 100% burn-in tested. Bulk value for 50+ units. OEM labeling available.
