240W 24V IP67 LED Driver — Mean Well HLG-240H Compatible
High-power constant-voltage LED driver designed as a drop-in replacement for the Mean Well HLG-240H-24A. Delivers a full 10A at 24V through a rugged aluminum enclosure rated IP67, suitable for the most demanding outdoor LED projects. The integrated 3-in-1 dimming port and programmable output via the built-in potentiometer provide installation flexibility that eliminates the need for external accessories.
Key Features
- 240W / 10A output — Highest-capacity 24V driver in the HLG-compatible range, powering long-run LED strips and large module arrays from a single unit
- IP67 fully potted — Waterproof internals withstand rain, snow, and temporary submersion — ideal for rooftop, tunnel, and underwater-adjacent installations
- 3-in-1 dimming + built-in pot — 1-10V, PWM, resistance dimming plus an onboard trim pot for quick brightness adjustment without a controller
- 95.5% peak efficiency — Industry-leading efficiency reduces energy waste and extends LED system lifespan by minimizing thermal stress
- Surge protection 4kV/6kV — Built-in surge immunity handles lightning-induced transients on outdoor power lines without external SPD modules
- -40°C to +80°C operation — Full-spec performance in arctic cold and desert heat without forced cooling
Technical Specifications
| Parameter | Value |
|---|---|
| Output Power | 240W (24V / 10A) |
| Input Voltage | 90-305VAC / 127-431VDC |
| Efficiency | 95.5% typical |
| Power Factor | >0.99 |
| Dimming | 3-in-1: 1-10V / PWM / Resistance + built-in pot |
| IP Rating | IP67 |
| Surge Protection | 4kV differential / 6kV common mode |
| Protection | OCP, OVP, OTP, short-circuit |
| Operating Temp | -40°C to +80°C |
| Dimensions | 230 × 73 × 46 mm |
| Weight | 1050g |
| Certifications | CE, CB, EAC, UL8750, FCC Class B |
| Warranty | 5 years |
| Mean Well Equivalent | HLG-240H-24A |
Applications
- Large-format LED video wall power distribution
- Stadium and arena perimeter lighting
- Highway tunnel illumination systems
- Commercial building facade LED washing
- Industrial yard and parking lot LED retrofit
Installation Notes
For installations requiring dimming, connect the 1-10V control signal to the Dim+/Dim- terminals (max 100mA sourcing capacity). The built-in potentiometer allows manual output adjustment from 50-100% without any external signal. Use 14 AWG or larger wire for output connections to minimize voltage drop at 10A. Maintain 10mm clearance around the housing for natural convection cooling.
Why Choose BrightLink
Our HLG-240H-compatible driver matches Mean Well’s electrical specifications at a fraction of the cost. Every unit undergoes 100% burn-in testing at full load for 4 hours before shipment. Project value available for quantities of 20+ units with custom labeling and reporting documentation.
