350W 24V Enclosed Power Supply — Mean Well LRS-350-24 Compatible
Ultra-slim enclosed LED power supply delivering 355W at 24V in a compact 1U-height form factor. Designed as a cost-effective alternative to the Mean Well LRS-350-24 for indoor LED installations where space inside the electrical panel or ceiling cavity is at a premium. The metal-mesh top provides excellent ventilation while the low-profile design allows stacking in standard 19-inch racks and narrow junction boxes.
Key Features
- 355W / 14.8A output — Powers extensive indoor LED strip runs, panel light arrays, and commercial lighting grids from a single supply
- 1U ultra-slim profile — Just 30mm height fits into tight ceiling plenums, furniture cavities, and standard equipment racks
- 300VAC surge rating — Withstands common power-line transients in commercial buildings without external protection circuits
-
90% efficiency — Low standby power consumption (<0.5W) meets international energy-saving standards
- Built-in active PFC — Power factor >0.95 reduces apparent power draw and complies with EN 61000-3-2
- Comprehensive protections — Over-current, over-voltage, over-temperature, and short-circuit protection with automatic recovery
Technical Specifications
| Parameter | Value |
|---|---|
| Output Power | 355W (24V / 14.8A) |
| Input Voltage | 85-264VAC / 120-370VDC |
| Efficiency | 90% typical |
| Power Factor | >0.95 (active PFC) |
| Surge Rating | 300VAC (5 seconds) |
| Ripple & Noise | <150mV p-p |
| Protection | OCP (110-200%), OVP (27-33V), OTP, short-circuit |
| Cooling | Forced air (built-in fan) |
| Operating Temp | -30°C to +70°C |
| Dimensions | 215 × 115 × 30 mm |
| Weight | 620g |
| Certifications | CE, CB, EAC, UL/cUL, FCC Class B |
| Warranty | 3 years |
| Mean Well Equivalent | LRS-350-24 |
Applications
- Commercial office LED panel and troffer lighting
- Retail store LED track and display lighting distribution
- Warehouse LED high-bay and low-bay systems
- LED video wall and digital signage power distribution
- Hotel corridor and common area ambient lighting
Installation Notes
Mount horizontally or vertically using the integrated mounting holes. Ensure at least 20mm clearance above and below the unit for airflow. For installations in enclosed cabinets, provide exhaust ventilation or use the built-in fan terminal for active cooling. Connect LED loads using the multi-position terminal block — parallel connections for multiple strip runs.
Why Choose BrightLink
offered 35% below Mean Well LRS-350-24 retail with identical form factor and pin-compatible terminal layout. No rewiring needed for drop-in replacement. Available in 12V, 15V, 36V, and 48V variants from the same product family. Volume discounts for 10+ units.
