200W 12V Enclosed Power Supply — Mean Well LRS-200-12 Compatible
Compact 1U enclosed power supply delivering 204W at 12V for indoor LED strip and module installations. The LRS-compatible form factor measures just 30mm tall, fitting inside cove lighting recesses, false ceiling cavities, and furniture-mounted LED controllers. Universal 85-264VAC input handles both 120V residential and 230V commercial mains without manual voltage selection switches.
Key Features
- 204W / 17A output — Drives up to 17 meters of 12V/m standard LED strip or 34 meters of 12V/high-density strip from a single supply
- 1U low-profile housing — 30mm height slides into tight spaces where traditional box-type supplies cannot fit
- Universal AC input — 85-264VAC range covers 100V (Japan), 120V (North America), 230V (Europe), and 240V (Australia) without DIP switch adjustment
- Active PFC — Power factor >0.95 meets international harmonic standards for commercial installations
- No-load consumption <0.5W — Complies with ErP Lot 6 standby power requirements for energy-efficient building certification
- LED-ready output — Low ripple (<100mV) output prevents visible flicker on sensitive LED strips at any dimming level
Technical Specifications
| Parameter | Value |
|---|---|
| Output Power | 204W (12V / 17A) |
| Input Voltage | 85-264VAC / 120-370VDC |
| Efficiency | 89% typical |
| Power Factor | >0.95 (active PFC) |
| Ripple & Noise | <100mV p-p |
| Standby Power | <0.5W |
| Protection | OCP (110-200%), OVP (13.2-16.8V), OTP, short-circuit |
| Cooling | Natural convection (no fan) |
| Operating Temp | -30°C to +70°C |
| Dimensions | 159 × 97 × 30 mm |
| Weight | 380g |
| Certifications | CE, CB, EAC, UL/cUL, FCC Class B |
| Warranty | 3 years |
| Mean Well Equivalent | LRS-200-12 |
Applications
- Residential cove and accent LED strip lighting
- Kitchen under-cabinet LED tape installations
- Retail display case and shelf LED illumination
- Hospital headwall and ambient LED lighting
- Hospitality room decorative LED features
Installation Notes
Mount using the 4 corner mounting holes or double-sided adhesive pad on the base. For ceiling cavity installations, maintain 30mm clearance on all sides for natural convection. Connect 12V LED strips using the output terminal block — observe polarity carefully as reverse connection will not damage the supply but will not illuminate the strip. For dimming, pair with a BrightLink PWM dimmer (model 121) between the supply and the LED strip.
Why Choose BrightLink
Identical footprint to the LRS-200-12 for drop-in replacement in existing installations. Fanless design ensures silent operation in noise-sensitive spaces. Available in 5V, 15V, 24V, 36V, and 48V from the same LRS-compatible family. Bulk value for 20+ units with OEM labeling.
