LED Power Supply – 15W 24V DIN Rail Mean Well HDR-15 Compatible

Ultra-Compact DIN Rail Power for Control Panels and Small LED Loads

Panel builders and lighting contractors who need reliable, space-efficient power supply solutions will appreciate the BrightLink BL-HDR15 series. At just 17.9mm wide, this 15W DIN rail driver occupies minimal space in electrical enclosures while providing stable, regulated DC output for LED indicators, small signage, and control circuitry.

Key Features

• 17.9mm Ultra-Narrow Profile — Saves valuable DIN rail space in crowded control panels; up to 20 units fit on a standard 35mm rail in a 400mm-wide enclosure
• Noiseless Operation — Convection-cooled design with no internal fan eliminates acoustic noise, ideal for offices, hospitals, and recording studios where LED indicators are visible
• Class 2 Output (5V/12V models) — Meets NEC Class 2 requirements for limited power sources, allowing use of thinner gauge wiring in plenum spaces without conduit
• DC OK LED Indicator — Built-in green LED provides instant visual confirmation of output status during commissioning and troubleshooting
• 100% Burn-In Testing — Every unit undergoes 24-hour full-load burn-in at the factory before shipping, ensuring field reliability from day one
• Wide Operating Temperature -30°C to +70°C — Derates gracefully to 80% load at 70°C, suitable for unventilated enclosures in warm environments

Technical Specifications

Typical Applications

• PLC & Control Panel Power — Provides 24V DC for PLC digital input circuits, sensor power, and relay coils in industrial automation cabinets
• LED Status Indicators — Powers small LED pilot lights and indicator strips on machine control panels and HMI enclosures
• Building Management Systems — Supplies power to BMS controllers, DDC modules, and network switches in electrical closets
• Emergency Exit Signage — Compact size fits inside exit sign enclosures for maintained LED illumination
• IoT Gateway & Sensor Hubs — Clean DC output with low ripple powers sensitive IoT edge devices and environmental sensors

Installation Notes

Simply snap onto standard 35mm DIN rail using the integrated spring clip. No tools required for mounting. For parallel redundancy applications, add external ORing diodes (not included). Input and output connections use standard screw terminals accepting up to 14 AWG wire. Ensure adequate ventilation around the unit — maintain 25mm clearance above and below for convection airflow.

Why Choose BrightLink?

BrightLink manufactures DIN rail power supplies in high volume, enabling competitive value for panel builders who standardize on our products across multiple projects. Each HDR-15 compatible unit carries UL 62368-1 and TUV EN 62368-1 certifications for global equipment integration. Our 3-year warranty and batch-traceable quality system ensure long-term supply chain confidence. volume options available for OEM partnerships.
