# Industrial LED Power Supply Metal Shell
Bluxled’s industrial LED power supply with heavy-duty metal shell is built for the most demanding commercial and industrial lighting environments â factories, mines, cold storage facilities, outdoor infrastructure, and large-scale commercial installations where standard drivers would fail prematurely. The robust metal shell enclosure is constructed from die-cast aluminium with IP65 sealing, providing complete protection against dust ingress and water jets. This is the driver specified when the installation environment is harsh, maintenance access is limited, and lighting uptime is non-negotiable.
Available in 150W, 200W, 300W, and 400W output ratings, this industrial LED power supply covers the full range of high-power commercial and industrial LED lighting applications. The wide output voltage options (12V, 24V, 36V, 48V) accommodate diverse LED configurations from high-bay luminaires to flood light arrays and tunnel lighting systems. Extended operating temperature range (-40°C to +85°C case temperature) ensures reliable performance in cold storage facilities, outdoor installations in extreme climates, and high-temperature industrial environments. Every unit is manufactured with industrial-grade components including 105°C rated electrolytic capacitors and conformal-coated PCBs for moisture and contaminant resistance.
Bluxled supplies this industrial metal shell LED power supply to wholesale distributors, mining and industrial supply companies, and commercial lighting contractors across Australia, Southeast Asia, and the Middle East. We offer project-specific OEM configurations including custom output voltages, specialised cable entry glands (M20, M25, PG), and compliance documentation for mining and hazardous area certifications. volume options is structured for the large-order quantities typical of industrial lighting projects.
Key Features
- Heavy-duty die-cast aluminium shell with IP65 dust-tight and water-jet protection rating
- Extended operating temperature range from -40°C to +85°C for extreme environment deployment
- Multiple wattage options: 150W, 200W, 300W, and 400W for high-power industrial LED applications
- Multiple output voltage options: 12V, 24V, 36V, and 48V for diverse LED configurations
- Industrial-grade 105°C capacitors and conformal-coated PCRs for extended service life in harsh conditions
- Surge protection up to 4kV line-to-earth and 2kV line-to-line for industrial power environments
- High efficiency up to 90% reduces total cost of ownership across large-scale installations
- Integrated metal cable glands (M20/M25) for sealed, strain-relieved cable entry
- CE, RCM, CB, and IP65 certified for Australian mining, industrial, and outdoor applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Output Voltage | 12V / 24V / 36V / 48V DC (model dependent) |
| Output Power | 150W / 200W / 300W / 400W (4 models) |
| Input Voltage Range | 90â305VAC, 47â63Hz (wide range) |
| Power Factor | > 0.95 (full load, > 50% load) |
| Efficiency | Up to 90% |
| Output Ripple | < 150mV p-p |
| Surge Protection | 4kV (L-E), 2kV (L-N) |
| Operating Temperature | -40°C to +85°C (case temperature) |
| Cooling Method | Free air convection (enhanced fin design) |
| Protection | Short circuit / Overload / Over-voltage / Over-temperature / Under-voltage |
| Enclosure Rating | IP65 |
| Housing Material | Die-cast aluminium (ADC12), powder-coated |
| Cable Entry | M20 / M25 metal cable glands (2 entries) |
| Dimensions (LÃWÃH) | 280 Ã 135 Ã 55 mm (200W model) |
| Weight | 1.8kg (200W model) |
| Mounting | Heavy-duty bracket mount with vibration-resistant hardware |
| Certifications | CE, RoHS, FCC, RCM, CB, IP65 |
| MTBF | > 80,000 hours |
| Warranty | 5 years |
Applications
1. Industrial high-bay LED lighting â high-power drivers for factory, warehouse, and distribution centre high-bay luminaires 2. Mining and quarry LED lighting â ruggedised drivers for surface and underground mining facility illumination 3. Cold storage and freezer lighting â extended low-temperature operation for refrigerated warehouses and cold chain facilities 4. Outdoor flood and area lighting â IP65 sealed drivers for sports field, car park, and perimeter security flood lighting 5. Tunnel and underpass lighting â reliable drivers for transportation infrastructure lighting with 24/7 operation requirements 6. Marine and port facility lighting â corrosion-resistant metal shell for wharf, dockyard, and maritime facility LED systems 7. Agricultural and horticultural lighting â sealed drivers for greenhouse, poultry farm, and agricultural facility LED installations
