LED Power Supply – 12V 60W Slim Driver

LED Power Supply 12V 60W Ultra-Slim Compact Driver

The 12V 60W slim LED power supply solves the spatial constraints common in modern LED lighting installations where ceiling cavities, aluminium extrusion channels, and furniture-integrated lighting leave minimal room for driver placement. With a height of just 19mm, this ultra-thin driver fits into the narrowest recesses, behind bulkheads, inside joinery, and within slimline luminaire housings where conventional drivers simply will not fit. Despite its compact profile, it delivers a full 60 watts at 12 volts DC, enough to power up to 4 metres of high-density LED strip or multiple lower-wattage fixtures.

Engineered for efficiency and thermal management in a constrained form factor, this slim driver uses high-density SMD topology and a thermally conductive potting compound that transfers heat to the aluminium base plate. The result is fanless, silent operation with efficiency up to 87% and reliable performance across the -20°C to +55°C operating range. Universal AC input (100-265VAC) and integrated protection circuitry make it suitable for installations across residential, commercial, and light-industrial environments without region-specific variants.

BluxLED supplies this 12V 60W slim LED driver in high volumes to lighting OEMs, furniture manufacturers, shopfitters, and electrical wholesalers. Our direct-from-manufacturer value is structured for competitive distribution, and we support OEM branding, custom cable configurations, and retail-ready packaging for private-label programs. All units ship CE and RoHS certified. Contact our sales team for sample requests and tiered quotation.

Key Features

• Ultra-slim profile with height of only 19mm for tight-space installations
• 12VDC constant voltage output at 60W (5A)
• High-density SMD topology in compact aluminium enclosure
• Fanless passive cooling via thermally conductive potting compound
• Efficiency up to 87% reducing heat generation in confined spaces
• Universal AC input: 100-265VAC for international compatibility
• Integrated protections: short-circuit, over-current, over-voltage, over-temperature
• No-load power consumption below 0.5W for standby compliance
• CE and RoHS certified with EN61347 safety compliance

Technical Specifications

Parameter	Specification
Output Voltage	12VDC
Output Power	60W
Output Current	0-5A
Input Voltage Range	100-265VAC
Input Frequency	47-63Hz
Power Factor	> 0.85 (at full load, 230VAC)
Efficiency	Up to 87%
Ingress Protection	IP20
Operating Temperature	-20°C to +55°C
Storage Temperature	-40°C to +85°C
Protection	Short-circuit / Over-current / Over-voltage / Over-temperature
Cooling	Passive (thermally conductive potting)
Enclosure Material	Aluminium base with plastic top cover
Dimensions (L x W x H)	160 x 50 x 19 mm
Weight	Approx. 200g
Certifications	CE, RoHS, EN61347
MTBF	> 40,000 hours
Warranty	3 years

Applications

• Kitchen cabinet and joinery-integrated LED strip lighting
• Aluminium extrusion channel LED installations with limited depth
• Retail display case and showcase LED illumination
• Bathroom mirror and vanity LED lighting behind bulkheads
• Wardrobe and walk-in-robe LED lighting systems
• Office furniture and work panel integrated task lighting
• Hotel room ambient LED lighting in recessed cavities

Frequently Asked Questions

What makes this 12V 60W driver different from standard LED drivers?

The primary differentiator is the ultra-slim form factor. At only 19mm in height, this driver is approximately 50% thinner than a conventional 60W LED driver. This allows installation in spaces where standard drivers cannot fit, such as behind slim bulkheads, inside shallow aluminium profiles, and within furniture cavities with minimal clearance.

Can this slim driver power a full 4-metre LED strip?

Yes, a standard 14.4W/m LED strip draws approximately 57.6W over 4 metres, which is within this driver’s 60W capacity. However, we recommend loading to no more than 80% (48W) for continuous operation, which supports approximately 3.3 metres of 14.4W/m strip. For full 4-metre runs, consider our 12V 80W or 12V 100W models.

Is this driver suitable for installation inside furniture?

Yes. The slim profile, fanless operation, and low heat output make this driver ideal for integration into furniture, joinery, and built-in cabinetry. The aluminium base should have contact with a mounting surface to assist heat dissipation. Ensure the installation location is not in direct contact with combustible materials.

Does this slim driver fit inside standard aluminium LED extrusions?

The 19mm height fits inside most wide-profile aluminium LED extrusion channels that are designed to conceal drivers. However, it will not fit inside narrow profile extrusions intended only for LED strip. Check the internal channel dimensions of your specific extrusion before ordering.

What is the minimum order quantity for this slim LED driver?

Standard MOQ is 200 units with tiered value at 500, 1000, and 5000-unit levels. OEM orders with custom branding start at 500 units. Sample quantities of 1-10 units are available at a premium cost for evaluation and prototype builds.

Can this driver be used with LED dimmers?

The standard model is non-dimmable. Dimmable versions supporting trailing-edge (TRIAC), leading-edge, or 0-10V dimming are available for OEM orders. If you require a dimmable slim driver for a project, specify your dimming protocol and order volume in your enquiry.

What certifications does this slim LED driver hold?

This driver carries CE and RoHS certifications and meets EN61347 safety requirements for LED electronic control gear. FCC compliance documentation is available for North American distribution. For additional market-specific certifications, contact our team to discuss options for your order volume.
