Overview
The BrightLink HDR-150-24 compatible DIN rail power supply combines high power density with an ultra-slim profile, delivering 150W of regulated 24V DC power from a unit just 32.5mm wide. Designed as a direct replacement for the Mean Well HDR-150-24, this driver snaps onto standard TS-35/7.5 or TS-35/15 DIN rails, making it the perfect choice for control panels, automation enclosures, and industrial LED lighting systems where space is at a premium.
With universal AC input (100-240VAC), high efficiency up to 92%, and a comprehensive suite of protection features, this power supply provides reliable, clean DC power for LED drivers, PLCs, sensors, relays, and other industrial control equipment. The convection-cooled design requires no fan, ensuring silent, maintenance-free operation.
Key Features
- 150W Output in Ultra-Slim Package – Only 32.5mm wide, saving valuable panel space while delivering substantial power
- Standard DIN Rail Mount – Compatible with TS-35/7.5 and TS-35/15 rails; tool-free snap-on installation
- 24V DC Output – 6.25A at 24V, the industry-standard voltage for industrial control and LED lighting systems
- Universal AC Input – 100-240VAC range covers all major global mains voltages
- High Efficiency – Up to 92% efficiency reduces heat generation and energy consumption
- DC OK Relay Contact – Built-in relay signal output for remote monitoring and system integration
- Comprehensive Protection – Short circuit, overcurrent, overvoltage, and overtemperature protection with auto-recovery
- Low Ripple and Noise – Less than 150mV ripple ensures clean power for sensitive electronics
- 3-Year Warranty – Industrial-grade reliability backed by full manufacturer warranty
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | HDR-150-24 Compatible |
| Output Power | 150W |
| Output Voltage | 24V DC |
| Output Current | 6.25A (max) |
| Input Voltage Range | 100-240VAC |
| Input Frequency | 47-63Hz |
| Efficiency | 92% (typical at full load) |
| Ripple and Noise | Less than 150mV p-p |
| Operating Temperature | -30C to +70C |
| Dimensions (W x H x D) | 32.5 x 125.2 x 107.5mm |
| Weight | Approx. 390g |
| DIN Rail | TS-35/7.5 or TS-35/15 |
| Certifications | CE, UL, EAC |
Applications
The HDR-150-24 compatible DIN rail power supply is designed for industrial and commercial environments where reliable 24V DC power is required in a compact form factor. Common applications include industrial control panel power distribution, PLC and automation system power, LED lighting control systems in commercial buildings, elevator and escalator control circuits, HVAC system controllers and actuators, security and access control systems, telecommunications equipment racks, and test and measurement equipment power.
Installation Notes
Installation is straightforward: simply snap the unit onto a standard TS-35 DIN rail. No tools are required for mounting or removal. Connect the AC input to terminals L (line) and N (neutral) using appropriately rated wire (minimum 16 AWG for the input circuit). The DC output terminals are clearly marked +V and -V. The DC OK relay contacts can be wired to a monitoring system or indicator lamp to signal power supply status. Ensure adequate ventilation around the unit – maintain at least 15mm clearance on each side and 40mm above and below for optimal thermal performance. The unit operates by natural convection cooling and requires no fan.
Why Choose BrightLink
BrightLink DIN rail power supplies are engineered to meet the demanding requirements of industrial automation and control applications. Each unit undergoes comprehensive testing including full-load burn-in, hi-pot testing, and output verification before leaving our facility. We offer competitive pricing, fast shipping, responsive technical support, and a 3-year warranty. Whether you are building a new control panel or upgrading an existing system, BrightLink provides the dependable power your installation requires.
