LED Strip Connector Clip – 2-Pin Solderless
Our 2-pin solderless LED strip connector clip is a practical solution for quick and reliable LED strip connections without the need for soldering tools. These clips are engineered for standard 8-10mm wide single-color LED strips, providing a secure mechanical and electrical connection with minimal effort. The transparent housing allows for visual inspection of the internal contacts, ensuring proper alignment and connectivity.
Each connector features high-conductivity copper contacts with a protective anti-corrosion coating, delivering stable current transmission with low resistance. The compact design measures approximately 12mm x 14mm, making it unobtrusive when installed in tight spaces. The clip mechanism provides firm grip on the PCB without damaging the copper pads.
Installation is straightforward: simply align the strip ends with the contacts, close the clip, and secure the locking mechanism. These connectors are ideal for corner turns, gap bridging, and repair applications where cutting and reconnecting LED strips is necessary. Rated for currents up to 3A and voltages up to 24V DC.
Specifications
| Parameter | Specification |
|---|---|
| Connector Type | 2-Pin Solderless Clip |
| Compatible Strip Width | 8-10mm |
| Contact Material | Copper, Anti-Corrosion Coated |
| Housing Material | Transparent Polycarbonate |
| Max Current | 3A |
| Max Voltage | 24V DC |
| Pins | 2 (Positive + Negative) |
| Dimensions | 12mm x 14mm |
These solderless clips are commonly used in residential cove lighting, retail display illumination, and DIY LED projects. The quick-connect design significantly reduces installation time and eliminates the risk of heat damage from soldering irons. Bulk packaging available for volume orders.
