LED RF Wireless Remote Controller – 2.4GHz Multi-Zone
The 2.4GHz RF wireless LED controller provides reliable remote operation for single-color, dual-white (CCT), RGB, and RGBW LED strip lighting systems. Operating on the interference-resistant 2.4GHz frequency band, this controller supports communication through walls and obstacles up to 30 meters in open space, eliminating the line-of-sight limitations of traditional infrared remotes.
The controller features a compact receiver unit measuring 85mm x 45mm x 23mm, easily fitting inside standard aluminum profiles or junction boxes. The touch-sensitive remote includes a color wheel for intuitive RGB selection, dedicated brightness and speed controls, and 20 built-in dynamic lighting modes including fade, jump, strobe, and music-sync. The receiver supports PWM dimming at 4KHz frequency, ensuring flicker-free video recording.
Multi-zone functionality allows one remote to control up to 4 independent zones, with each zone supporting pairing of up to 10 receiver units. This enables synchronized or independent control of multiple light areas from a single handheld remote. The system retains settings after power loss through non-volatile memory storage.
Specifications
| Parameter | Specification |
|---|---|
| Frequency | 2.4GHz ISM Band |
| Control Range | Up to 30m Open Space |
| Output Channels | 1CH / 2CH / 3CH / 4CH / 5CH |
| PWM Frequency | 4KHz Flicker-Free |
| Input Voltage | DC 12-24V |
| Max Output | 6A per Channel |
| Zones Supported | Up to 4 Independent Zones |
| Remote Battery | CR2032 (Included) |
Applications include residential mood lighting, hotel room automation, commercial display illumination, and architectural accent lighting where wireless control eliminates the need for additional control wiring. Compatible with all major LED strip types at 12V and 24V DC operation.
