WiFi / Bluetooth Smart LED Controller — Tuya Ecosystem, Voice-Activated
Bring LED lighting into the smart-building ecosystem with the BrightLink WiFi + Bluetooth dual-protocol controller. Native Tuya / Smart Life integration means instant compatibility with thousands of smart-home devices, while Bluetooth provides local fallback control when WiFi is unavailable. End users adjust brightness, color temperature, and RGB color from their smartphone — or simply speak a command to Alexa or Google Home — without purchasing a proprietary hub or bridge.
Key Features
- Dual-mode connectivity — WiFi 2.4 GHz for cloud-connected remote access plus Bluetooth 5.0 for instant local pairing during installation and offline control
- Tuya / Smart Life native — Works with the world’s largest IoT platform, enabling cross-device automation with smart plugs, sensors, curtains, and thermostats
- Voice assistant support — “Hey Google, set the living room to 50% brightness” works out of the box with Alexa and Google Home integration
- Music sync mode — Built-in microphone analyzes ambient audio and maps beat frequency to real-time color and brightness changes — popular for entertainment and retail environments
- 16 million colors + tunable white — Full RGB color wheel plus dedicated CCT slider (2700K–6500K) on RGBW strip configurations
- Scene & schedule automation — Create custom lighting scenes with timer triggers, sunrise/sunset events, and geofencing-based on/off rules
- OTA firmware updates — Receive feature upgrades and security patches over-the-air through the Tuya platform without physical access to the controller
Technical Specifications
| Parameter | Value |
|---|---|
| WiFi | 2.4 GHz 802.11 b/g/n |
| Bluetooth | BLE 5.0 |
| App Platform | Tuya Smart / Smart Life (iOS 11+ / Android 5.0+) |
| Voice Assistants | Amazon Alexa, Google Home |
| Input Voltage | DC 12V–24V |
| RGB Output (3CH) | 3 × 2A max |
| RGBW Output (4CH) | 4 × 1.5A max |
| Max Load | 72W @ 12V / 144W @ 24V |
| Music Sync | Built-in MEMS microphone, real-time beat detection |
| Scene Memory | Unlimited (cloud-stored via Tuya) |
| OTA Updates | Yes, via Tuya cloud |
| Dimensions | 68 × 45 × 19 mm |
| Certifications | CE, RoHS, FCC, Tuya Certified |
Applications
- Smart-home residential installations — Bedroom, living room, and kitchen LED strips controlled by voice, schedule, or geofence triggers
- Airbnb & short-term rental management — Remote on/off control and automated welcome lighting sequences via the Tuya cloud dashboard
- Café & boutique retail ambiance — Music-sync mode creates dynamic atmosphere that responds to the venue’s playlist and customer energy
- Co-working space zone lighting — Group controllers by zone and automate warm-white focus lighting during business hours, color accent mode during events
- Hospitality wayfinding & decorative lighting — Schedule-driven color temperature shifts support circadian lighting design in hotels and wellness centers
Installation Notes
Wire the controller between the LED power supply and the LED strip, observing correct polarity. Power on the controller and enter pairing mode by holding the reset button for 5 seconds until the indicator LED flashes rapidly. Open the Tuya Smart or Smart Life app, tap “Add Device,” and follow the auto-scan prompt. For Bluetooth-only setup (no WiFi), the app will detect the controller via BLE within 2 meters. Ensure the 2.4 GHz WiFi network is selected — 5 GHz networks are not supported.
Why Choose BrightLink
As a Tuya-certified hardware partner, BrightLink delivers pre-tested firmware that passes OTA validation on every major app version. Our direct-from-manufacturer value makes smart controllers affordable for volume deployment, and we provide API documentation for custom integrations with BMS and property-management platforms.
