LED RF Remote Dimmer Switch – Handheld 1CH Pocket Size
The compact handheld RF remote dimmer switch provides simple, portable brightness control for single-color LED lighting systems. Small enough to fit in a pocket or mount on a keychain at just 55mm x 35mm x 12mm, this remote includes a large rotary dimmer wheel for intuitive brightness adjustment and separate ON/OFF button with LED status indicator. Operating on 433MHz RF, the remote communicates reliably through walls and furniture up to 20 meters.
The paired receiver module (included) connects inline between the power supply and LED strip, accepting DC 12-24V input and delivering up to 8A output. The receiver features soft-start dimming that gradually increases brightness over 0.8 seconds, protecting LED drivers and creating a premium lighting experience. PWM frequency of 2KHz ensures flicker-free operation for both direct viewing and camera capture.
One remote can pair with multiple receivers for synchronized group control, and each receiver can accept pairing from up to 4 remotes for multi-point control. The system retains the last brightness setting through power cycles via non-volatile memory. An optional wall-mount bracket (sold separately) converts the handheld remote into a wall station.
Specifications
| Parameter | Specification |
|---|---|
| Wireless Frequency | 433MHz RF (ISM Band) |
| Control Range | Up to 20m (Through Walls) |
| Remote Dimensions | 55mm x 35mm x 12mm |
| Receiver Output | 1CH, 8A Max |
| Receiver Input | DC 12-24V |
| Max Receivers per Remote | Unlimited (Same Code) |
| Max Remotes per Receiver | 4 |
| Remote Power | CR2025 Battery (Included) |
Perfect for under-cabinet kitchen lighting, wardrobe and closet illumination, bedside reading lights, display case accent lighting, and hobby workbench illumination where simple, portable dimming control is preferred over complex multi-function remotes or smartphone app control.
