LED Power Supply – 600W 24V IP67 Mean Well HLG-600H Compatible

Maximum Power for Large-Scale LED Installations

When your project demands serious wattage, the BrightLink BL-HLG600H delivers 600W of clean, regulated DC power in a single IP67-rated enclosure. Designed as a drop-in alternative to the Mean Well HLG-600H, this driver eliminates the need to parallel multiple smaller units — one HLG600H can power an entire facade of LED fixtures or a high-bay warehouse lighting array.

Key Features

• 600W High-Power Single Unit — Consolidates what would normally require 2-3 smaller drivers into one installation point, reducing wiring complexity and failure points
• Multiple Output Voltages — Choose from 12V (50A), 15V (40A), 20V (30A), 24V (25A), 36V (16.7A), 48V (12.5A), or 54V (11.1A) to match your specific LED string configuration
• True IP67 with 10kV Surge Rating — Highest surge protection in the HLG family, designed for areas with frequent lightning activity or unstable industrial power grids
• Active Power Factor Correction — PF > 0.95 across the full input range, meeting strict utility requirements for commercial installations over 1000W total connected load
• Programmable Constant Current / Constant Voltage — Switch between CC and CV modes to drive LEDs directly or power LED strips with precise voltage regulation
• Smart Fan with Thermal Management — Internal fan activates only under high load or ambient temperature, maintaining silence during normal operation while protecting components at full capacity

Technical Specifications

Typical Applications

• High-Bay Warehouse Lighting — Single driver powers 10-15 high-bay LED fixtures in logistics centers, reducing maintenance intervals and electrical panel space
• Large-Scale Facade Media Walls — Drives long runs of pixel-addressable LED modules for architectural media facades and digital signage walls
• Stadium & Arena Flood Lighting — High current output handles the massive LED arrays used in sports venue illumination with consistent brightness
• Greenhouse Horticulture — IP67 rating withstands high-humidity growing environments while powering full-canopy grow light systems
• Street & Area Lighting Networks — Centralized high-power driver for pole-mounted LED luminaires with 0-10V dimming for smart city schedules

Installation Notes

Due to the 600W output capacity, use appropriately rated output cables (minimum 10 AWG for 24V at 25A). The integrated fan requires 50mm clearance on one side for airflow. For dimming installations, use shielded control cables and keep signal wires separated from AC mains to prevent interference. Mount vertically or horizontally using the 4x M5 mounting points.

Why Choose BrightLink?

Our HLG-600H compatible driver is manufactured in our own facility, allowing us to control quality from PCB assembly to final burn-in testing. Each unit ships with full test reports documenting output accuracy, efficiency, and protection thresholds. UL and TUV certifications ensure compliance with North American and European electrical codes. 5-year warranty covers parts and labor with direct-from-manufacturer replacement service.
