BrightLink 150W IP67 LED Driver — XLG-150 Series Compatible
Engineered for demanding outdoor lighting installations, the BrightLink BL-XLG150 delivers reliable 150W power in a fully sealed IP67 enclosure. This driver serves as a drop-in replacement for the Mean Well XLG-150 series, offering identical mounting dimensions and electrical characteristics at a competitive direct-from-manufacturer value point.
Whether you’re powering street lights, facade illumination, or landscape lighting, the BL-XLG150 maintains stable output across wide temperature swings and harsh weather conditions — from freezing winters to scorching summers — while achieving over 90% efficiency at full load.
Key Features & Benefits
- Full IP67 Waterproof Rating — Completely sealed aluminum housing withstands rain, dust, and temporary submersion, making it ideal for outdoor and wet-location installations without additional enclosures.
- 100-305VAC Universal Input — Accepts virtually any AC mains supply worldwide (142-431VDC compatible), eliminating the need for region-specific SKUs and simplifying inventory management.
- Constant Current + Constant Power — Built-in CP (Constant Power) circuitry ensures LED current remains stable regardless of input voltage fluctuations, extending LED lifespan and maintaining consistent light output.
- 90%+ Energy Efficiency — Minimizes heat generation and electricity waste, reducing total cost of ownership over the product’s 50,000+ hour operational life.
- Comprehensive Protection Suite — Short circuit, overvoltage, over-temperature, and overload protection activate automatically to prevent damage to both the driver and connected LEDs.
- 5-Year Warranty — Backed by BrightLink’s industry-leading warranty with dedicated technical support for project specification and after-sales service.
Technical Specifications
| Model | BL-XLG150 |
| Rated Power | 150W |
| Input Voltage Range | 100 ~ 305VAC / 142 ~ 431VDC |
| Output Voltage (CC Mode) | 27 ~ 54VDC |
| Max Output Current | 2800mA (adjustable) |
| Power Factor | >0.95 (at full load) |
| Efficiency | >90% |
| IP Rating | IP67 |
| Operating Temperature | -40°C ~ +85°C (case) |
| Dimensions (L×W×H) | 199 × 63 × 35.5mm |
| Weight | Approx. 680g |
| Protections | Short Circuit / Overvoltage / Overload / Over Temperature |
| Certifications | UL, CE, CB, PSE, EAC, KC, SAA |
| Expected Lifespan | >50,000 hours |
| Warranty | 5 Years |
Typical Applications
- Street & Road Lighting — IP67 sealing and wide temperature range make it the go-to choice for municipal and highway LED luminaire projects.
- Building Facade & Architectural Lighting — Reliable performance in exposed outdoor positions on building exteriors, bridges, and monuments.
- Landscape & Garden Lighting — Withstands irrigation spray, rain, and ground-level moisture without additional protection.
- Tunnel Lighting — Handles vibration from heavy traffic while delivering stable illumination in high-humidity tunnel environments.
- Flood & Area Lighting — Powers high-bay outdoor floodlights for sports fields, parking lots, and construction sites.
Installation Notes
Mount using the built-in M4 screw holes on the aluminum housing. Connect AC input to the integrated flying leads (L/N/PE). For constant current mode, set the output current via the internal potentiometer or select from pre-set dip switch values. Ensure adequate airflow around the driver for optimal thermal performance.
Why Choose BrightLink?
As a direct manufacturer, BrightLink eliminates middleman markups while maintaining strict quality control at every production stage. Every BL-XLG150 unit undergoes 100% burn-in testing, hi-pot testing, and functional verification before shipping. We hold UL, CE, CB, and 20+ international certifications, and our dedicated engineering team provides free technical consultation for project specifications, lighting design, and compatibility verification. volume options available for contractors and OEM partners.
