LED KNX Controller Actuator 4CH DIN Rail

LED KNX Controller Actuator 4CH DIN Rail – Building Automation Integration for LED Lighting

This 4-channel KNX LED controller brings professional LED lighting control into the KNX building automation ecosystem. Mounted on standard DIN rails, this actuator connects directly to the KNX bus, allowing LED strip lights to be controlled by KNX switches, sensors, touch panels, and building management systems. Ideal for premium residential and commercial projects where KNX is the backbone of the building automation infrastructure.

Key Features

• KNX Bus Compatible: Full KNX/EIB protocol support for seamless integration with KNX building automation systems
• 4 Channel Output: Independent control of 4 LED channels – RGBW, 4x single color, or 2x CCT
• DIN Rail Mount: Standard DIN rail form factor for clean installation in electrical distribution panels
• Dimming Output: PWM dimming with smooth, flicker-free control from 0% to 100%
• Scene Control: Store and recall up to 8 lighting scenes via KNX scene objects
• Logic Functions: Built-in logic blocks for autonomous operation without central controller
• Status Feedback: Reports dimming level, on/off status, and fault conditions back to KNX bus
• Bus Power Powered: Draws operating power directly from the KNX bus – no additional power supply needed for logic
• ETS Configuration: Programmed using standard ETS (Engineering Tool Software) with provided application program

Applications

Designed for KNX-equipped buildings including luxury residences, premium offices, hotels, hospitals, educational facilities, and government buildings. The KNX standard ensures long-term compatibility and vendor independence – your LED lighting control investment is protected by the open standard backed by over 500 manufacturers worldwide.

Compatible With

• 12V/24V LED strip lights (RGBW, single color, CCT)
• KNX switches, push buttons, and touch panels
• KNX presence and motion detectors
• KNX weather stations and daylight sensors
• KNX visualization systems (Gira HomeServer, Jung SmartVisu, etc.)

Note: Requires KNX bus power supply and ETS software for configuration. LED power supply (12V/24V) is not included and must be sized according to total LED load.
