Overview
The BrightLink SDR-120-24 is a high-efficiency 120W 24V DIN rail power supply designed as a compatible replacement for the Mean Well SDR-120-24. Featuring active PFC and slim profile design, this power supply is perfect for industrial control panels, automation systems, and DIN rail mounting applications requiring reliable DC power.
Key Features
- 120W output power with 24V DC output voltage
- DIN rail TS-35 mounting for easy installation
- High efficiency up to 94%
- Active PFC function for power quality
- Universal AC input range 90-264VAC
- DC OK relay contact for status monitoring
- 130-150% peak load capability
- Slim metal case design saves panel space
- Comprehensive protection features
- 3-year warranty for industrial reliability
Technical Specifications
| Specification | Value |
|---|---|
| Output Power | 120W |
| Output Voltage | 24V DC |
| Output Current | 5A |
| Input Voltage Range | 90-264VAC |
| Input Frequency | 47-63Hz |
| Efficiency | 94% |
| IP Rating | IP20 |
| Operating Temperature | -25°C to +70°C |
| Dimensions | 125 × 100 × 56mm |
| Weight | 0.65kg |
| Warranty | 3 years |
Applications
- Industrial control panels and automation systems
- PLC and HMI power supply
- Machine tool and manufacturing equipment
- Building automation and HVAC systems
- Telecommunications equipment
- Test and measurement instruments
- Security and surveillance systems
Installation Notes
The SDR-120-24 features standard TS-35 DIN rail mounting for quick and secure installation in control panels. The slim profile design maximizes panel space utilization. Connect the AC input to L and N terminals, and the DC output to +V and -V terminals. The DC OK relay contact can be used for remote status monitoring. Ensure adequate ventilation around the unit and maintain proper clearance from heat sources.
Why Choose BrightLink
BrightLink industrial power supplies are engineered for demanding applications requiring reliable performance and long service life. Our SDR-120-24 compatible power supply features the same high efficiency, active PFC, and DIN rail mounting as the original Mean Well model. With comprehensive protection features including overcurrent, overvoltage, and overtemperature protection, plus a 3-year warranty, BrightLink provides dependable power for your industrial applications.
