Corner / Angle Aluminum Profile

Overview

Sharp 45-degree angles deserve equally sharp finishing details. BrightLink’s corner aluminum LED profile is precision-extruded at a true 45-degree angle, creating seamless illuminated corners where two surfaces meet — inside corners of display cases, the junction of walls and ceilings, stair nosing edges, and furniture detail lighting. The anodized aluminum body doubles as a heatsink while the included frosted polycarbonate diffuser eliminates LED hotspots for a clean, continuous line of light.

Key Features

• True 45-Degree Angle — Precision-extruded at exactly 45° with tight angular tolerance (±0.5°), ensuring consistent corner illumination without gaps or misalignment between the two faces
• Anodized Aluminum Construction — 6063-T5 aluminum alloy with brushed silver or matte black anodized finish provides excellent heat dissipation and a premium architectural appearance
• Frosted PC Diffuser Included — Opal polycarbonate diffuser snaps into the channel, spreading LED light evenly and eliminating individual LED dots for a seamless glow effect
• Standard 10mm Internal Width — Accommodates all common LED strip types (3528, 2835, 5050, COB) up to 10mm PCB width with self-adhesive backing for easy strip installation
• Multiple Length Options — Available in 1-meter and 2-meter lengths; can be cut to custom sizes with a standard hacksaw or miter saw for exact-fit installations
• Complete Mounting Hardware — Includes mounting clips, end caps, and screws for surface mounting on walls, cabinets, furniture, or any flat substrate

Technical Specifications

Applications

• Inside Corner Lighting — Creates elegant accent lighting where two walls meet at a corner, adding depth and atmosphere to living rooms, hallways, and commercial spaces
• Cabinet & Furniture Detail — Illuminates the inside corners of display cabinets, bookshelves, and wardrobe interiors for both functional task lighting and visual appeal
• Stair Nosing & Edge Lighting — Provides visible edge definition on stair treads and platform edges, combining safety illumination with modern architectural design
• Retail Display Framing — Frames product display areas with clean lines of light at 45-degree angles, drawing customer attention to featured merchandise
• Cove & Soffit Transitions — Bridges the transition between cove lighting on walls and ceiling soffits, creating a continuous illuminated architectural detail

Installation Notes

Cut the aluminum profile to length using a fine-tooth hacksaw or miter saw with a non-ferrous blade. Deburr cut edges with a file before installing end caps. Peel the LED strip’s adhesive backing and press firmly into the channel, ensuring full contact with the aluminum base for heat dissipation. Snap the diffuser into place from one end. For mitered corner joints, cut both profiles at 45° and use a corner connector or silicone adhesive to join them seamlessly.

Why Choose BrightLink

BrightLink extrudes all aluminum profiles in our own facility using premium 6063-T5 alloy, ensuring consistent wall thickness, smooth anodized finishes, and precise angular tolerances that affordable extrusions can’t match. Our corner profiles are specifically designed with reinforced internal ribs at the 45° bend for added rigidity. direct-from-manufacturer value means you get professional-grade architectural lighting components at wholesale costs. Available in silver, black, and white finishes with same-day shipping on standard lengths. 5-year warranty on aluminum profiles.
